OR Zinc Alloy Mini Air Pressure Regulator 16BAR

Temperature Range: 0-60 Degree
Mounting Type: Pipe/Foot/Plate Mounting
Primary Pressure: 1-16 bar
Prepares Air Properly For All Types Of Compressed Air Tools And Equipment
The Filter Removes Solid Particles And Condensates With Compressed Air
Step Less Regulator Accurately Maintains Air Pressure Over A Wide Range Of Flows
Micro-Fog Lubricator Supplies Lubricating Oil To Working Pneumatic Equipment In Proper Proportion
Protect Your Air Tools With Much Longer Life

Model	MIN			MIDI			MAXI
	OR-1/8"-MINI	OR-1/4"-MINI	OR-3/8"-MINI	OR-3/8"-MIDI	OR-1/2"-MIDI	OR-3/4"-MIDI	OR-3/4"-MAXI	OR-1"-MAXI
	OR-1/8"--7MINI	OR-1/4"--7MINI	OR-3/8"--7MINI	OR-3/8"-7-MIDI	OR-1/2"-7-MIDI	OR-3/4"-7-MIDI	OR-3/4"-7-MAXI	OR-1"-7-MAXI
Medium	Filtered compressed Air(lubricated or unlubricated)
Medium	Filtered compressed Air(lubricated or unlubricated)
Features of Structure	MINI/MIDI:DDiaphragm type regulator;MAXI:Piston regulator
Features of Structure	MINI/MIDI:DDiaphragm type regulator;MAXI:Piston regulator
Mounting Type	pipe/foot/Plate mounting
Assembly position	any
Connection	G1/8"	G1/4"	G3/8"	G3/8"	G1/2"	G3/4"	G3/4"	G1"
Standard Flow Rate	800	1500	1700	3200	3500	3500	11000	11500
Standard Flow Rate	1000	1600	1800	3300	4000	4500	12000	12500
Working Pressure	0.5-12 bar/0.5-7bar
Working Pressure	0.5-12 bar/0.5-7bar
Working Temperature	0-60°C
Working Temperature	0-60°C
Primary Pressure	1-16 bar
Primary Pressure	1-16 bar
